High Quality Compact Wastewater Treatment System Membrane Bioreator
Municipal
1. The integrated sewage treatment equipment is buried below the
surface, and the surface above the equipment can be used as
greening or other land, without the need for building houses,
heating and heat preservation.
2. The secondary biological contact oxidation treatment process
adopts pushed-flow biological contact oxidation, and the treatment
effect is better than the fully mixed biological contact oxidation
tank or the two-stage series fully mixed biological contact
oxidation tank. Compared with the activated sludge tank, it has a
smaller volume, stronger adaptability to water quality, better
impact load resistance, stable effluent water quality and no sludge
expansion. The new type of elastic stereoscopic packing is used in
the tank, with large specific surface area, easy to hang the
membrane of microorganisms, and demembrane. Under the same organic
load condition, the removal rate of organic compounds is high,
which can improve the solubility of oxygen in the air in water.
3. The biological contact oxidation method is adopted in the
biochemical tank. The volume load of the filler is relatively low.
4. The deodorization method of the buried domestic sewage treatment
equipment includes conventional high-altitude exhaust and soil
deodorization measures.
5. The whole equipment processing system is equipped with fully
automatic electrical control system and equipment fault alarm
system, which runs reliably. Usually, it does not need special
personnel to manage, but only needs timely maintenance of the
equipment.
| Model | Water capacity(m3/h) | Reference outside size(L*W*H) mm | Qty(set) | Weight(T) | Air volume(m3/min) |
| AUMBR-0.5 | 0.5 | 3000*1500*2000 |
1 | 1.5 | 0.15 |
| AUMBR-1 | 1 | 4000*1500*2000 | 1.7 | 0.3 |
| AUMBR-2 | 2 | 5000*2000*2000 | 2.5 | 0.6 |
| AUMBR-3 | 3 | 7000*2000*2500 | 3.5 | 0.9 |
| AUMBR-5 | 5 | 10000*2500*2500 | 4.5 | 1.5 |
| AUMBR-10 | 10 | 16000*2500*2500 | 8.4 | 3 |
| AUMBR-20 | 20 | 16000*2500*2500 | 2 | 16.8 | 6 |
Several usage methods of integrated sewage treatment equipment:
1. Be able to treat the comprehensive wastewater of living system
and its similar organic wastewater;
2. It is made of glass fiber reinforced plastic and stainless
steel, with excellent properties of corrosion resistance and
anti-aging, and its service life is over 50 years;
3. The whole set of equipment is simple in construction and easy in
operation. All the mechanical equipment is controlled by
automation.
Buried sewage treatment technology has a variety of, under the
premise of water standards, the outstanding advantages are:
1. The equipment is buried under the surface, which can be
afforested and the environment is beautiful.
2. Generally, the whole equipment does not need special personnel
to manage.
3. The floor space can be reduced. Parking lots and other
facilities can be built above the equipment.
4. No impact on the surrounding environment, low sludge production,
noise less than the standard of the second class area.
5. Simple operation, new technology, good effect and long service
life.
6. The equipment can be arranged according to the standard or
special arrangement according to the terrain.
Equipment construction:
All pipes of the sewage treatment integration equipment are PVC
pipes or stainless steel pipes, and the connections between pipes
are bonded with PVC binder or welded with stainless steel. The
packing USES the suspension type biological packing as the
biological carrier, the biomass is big, hangs the film easily, does
not knot the ball, does not block.
Installation and maintenance:
1. Foundation: If WSZ series equipment is placed above the floor,
only a concrete floor with the same shape as the equipment needs to
be prepared as the foundation. The foundation pressure must be
greater than 4T/m2, and it should be horizontal and smooth. If the
equipment is buried below the floor, the elevation of the
foundation shall be less than or equal to the elevation of the
equipment and no water is allowed to accumulate in rain.
2, Installation: According to the installation diagram in place,
each box in place in turn, the position and direction of the box
should not be put wrong, spacing each other should be accurate, and
connected to the pipeline. Fill the equipment with clean water and
check whether there is any leakage in the pipes. If there is no
leakage, cover the box with soil until the equipment checks the
holes and level the ground. Connect the control line of the
electric control box to the water pump, connect the electric
control box to the power supply, pay attention to the fan, motor
steering, and the direction indicated by the fan.
Application of integrated sewage treatment equipment:
1. Hotels, restaurants and nursing homes;
2. Residential communities, villages and market towns;
3. Station, expressway service area, harbor wharf and ship;
4. Factories, mines, troops, tourist spots and scenic spots;
5. Industrial organic wastewater similar to domestic sewage, such
as food industry.
Packing and Delivery
1. The normal package is wooden box(Size: L*W*H). If export to
European countries,the wooden box will be fumigated.If container is
too tighter,we will use pe film for packing or pack it according to
customers special request.
2. We also support 20',40' container delivery, use soft packaging
to protect machine well. If export to european countries,the wooden
box will be fumigated.If container is too tigher,we will use pe
film for packing or pack it according to customers special request.
FAQ:
Q: Are You Trading Company Or Manufacture?
A: We Are Both Manufacture And Trading Company. We Have Over 30
Years' Professional Experience As a Waste Water Treatment Equipment
Manufacturer And Engineering Service Enterprise.
Q : What Are Your Main Products?
A:Keywords :Sludge Dewatering Machine Equipment, Screw Type Sludge
Dewatering Press Sludge Screw Press, Dewatering Sludge Machine
Screw Press ,Sewage Treatment Equipment ,Sludge Treatment
Plant,Screw Press Sludge Dewatering ,Dewatering Sludge,Dewatering
Machine For Sludge, Dewatering Sludge Machine Screw Press, Rotary
Drum Bar Screens, Equipment DAF, DAF Price ,Dissolved Air Flotation
System Price, Sludge Shaftless Screw Conveyor,Chemical Dosing
Device ,MBBR Price,MBBR Media,Disc Diffuser, Polymer Preparation
Chemical Dosing System,
Q: How Can I Find The Suitable Model?
A: Please Provide Flow Rate, Solids Content And Sludge Type, We Can
Assist You In Model Selection.
Q: Where Is Your Factory Located?
A: Yixing City, We are in the famous city of environmental
protection equipment ,professional for Sludge screw press
dewatering Machine ,Which Is Very Close To Shanghai With Only Less
Than 3 Hours' Driving. Welcome for your visiting.
Q: Do You Provide OEM Service?
A: Yes. We Can Do The Customized Design According To Your Different
Request for sludge Dewatering.
Q: How About The Production Capacity Of Your Company?
A: Our Factory Covers Area Over 22,000M2 And Produces Machines 2000
Sets Per Year.
Q: How Could We Trust You And Your Company? Is This Your First Time
Transaction?
A: A: Our Company Has More Than 30 Years Professional Experience.
We Cooperate Over 1000 Customers.In China And Overseas. We Export
Nearly 60 Countries All Over The World.And We Have More Than
60+Patents, CE,ISO 9001,SGS Certificates. And We Have Company In
Japan , Great Technology And Great Quality.
Q: Do You Offer After-Sales Service?
A: Video Technical Support, Online Support,Spare Parts,Field
Maintenance Repair Service
Q: How Long is Your Warranty?
A: 2 Years After The Arrival Of The Goods. During This Period, As
Long As It Is Not a Man-Made Damage, We Send The Damaged Parts Free
Of Charge.
Q: What About Your Produce Time?What Kind Of Transportation Do You
Offer?
A:Within 30 Days Against Down Payment. Air, Land & Sea .
Q: What Kind Of Payment Do You Accept?
A: T/T, L/C, Paypal, Cash, D/P, D/A, Western Union, Money Gram
